DC Fast Chargers 30 KW

Experience the future of EV charging with our 120 kW DC fast charger, charging electric vehicles up to 80% in just 45 minutes. Attract more customers and eliminate range anxiety while promoting sustainability. Upgrade your charging station today and lead the way in the green mobility revolution.

  • Surge Protection
  • Earth Detection
  • Power Theft Protection
  • Overheat Safety
  • Auto Power Cut Off
Product Features

✓

Compliance Standards

IOS/IEC 15118 and DIN 70121 compliant
✓

Communication Protocol

Powered with OCPP 1.6 for communication
✓

Gun Options

Single/Dual/Custom Gun (CCS2) compliant
✓

Integration Capability

CAN interface enabled for PMI (Power Module Integration)
✓

User Interface

Human Machine Interface (HMI) friendly
✓

Power Ratings

Suitable for 30 kW / 60 kW / 120 kW rating
✓

Authentication Support

RFID/NFC supportive for authentication
✓

Network Connectivity

Equipped with 4G, Ethernet-10/100, Wi-Fi for network connectivity
Product System Overview

The CCS2 controller is developed to function as a Supply Equipment Communication Controller (SECC) between the communication medium for electric vehicles (EVs) and electric vehicle supply equipment (EVSE).
It is an integral component of a charging station, and it offers a configuration that incorporates the standards specified by DIN 7012, ISO 15118, plug and charge (PnC) and Plug and Play (PnP), particularly for a fast DC charger.
Moreover, the CCS2 controller allows the user to integrate additional components with DC chargers, such as:
  • Power Modules, Insulation Monitoring Device, AC / DC Energy Meter
  • RFID Module, LED Module
Product Specification

Input and Output Supply
440v-60kW-3Phase
Protection
Over Voltage, Under Voltage, Current Leakage Detection
General Specifications
Dual CCS-2 Gun
Connectivity
Ethernet Interface / 3G / 4G
Communication Protocol
440v-30kW-3Phase
Compatible With
Charger Power Details
Single Gun 30 kW + Type-2 AC
DC 30 KW
Single Gun 60 kW + Type-2 AC
DC 60 KW
Single Gun 120 kW + Type-2 AC
DC 120 KW
Top Features
  • ✓IOS/IEC 15118 compliant
  • ✓OCPP 1.6 communication
  • ✓CCS2 compliant guns
  • ✓CAN interface for PMI
  • ✓HMI friendly
  • ✓30kW / 60kW / 120kW options
  • ✓RFID/NFC authentication
  • ✓4G, Ethernet, Wi-Fi connectivity
